EI 14 Audio Frequency Transformer , Audio Power Transformer PINS Installation

EI 14 Audio Frequency Transformer , Audio Power Transformer PINS Installation
EI 14 Audio Frequency Transformer , Audio Power Transformer PINS Installation

Large Image :  EI 14 Audio Frequency Transformer , Audio Power Transformer PINS Installation Get Best Price

Product Details:
Place of Origin: China
Brand Name: Shinhom
Model Number: AT1420
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Carton
Delivery Time: 4~8 Weeks
Payment Terms: T/T
Supply Ability: 1000000/MONTH
Detailed Product Description
Certification: ISO9001-2000, UL Core Material: Silicon Steel Sheet
Type: Audio Transformer Installation: PINS
Operating Temperature: -25℃ To +125℃ Shape Of Core: EI14
High Light:

smd audio transformer

,

ei type transformer

EI14 Audio Transformer,PCB Transformer and Audio Equipment Transformer,Low Frequency Transformer



FEATURES:



  1. Isolated telecommunication transformer
  2. SMD fax modem telecom transformers SMD
  3. Audio meets UL 1950 or EN60950 telecom transformer
  4. RoHS Directive-compliant
  5. Widely used in audio systems



Electrical specification



1. L(1-3): 24.5H±30% @100Hz,0.1V
            6.6H±30% @1KHz,0.1V
2. L(4-5)=(5-6): 1.1H±30%@100Hz,0.1V
                      263mH±30%@1KHz,0.1V
3. DCR(1-3): 760~820Ω
4. DCR(4-5)=(5-6): 43~50Ω
5. Z(1-3): 16KΩ±10% @100Hz
            144KΩ±10% @1KHz
6. Z(4-5)=(5-6): 213~216Ω@100Hz
                      3.3KΩ±10%@1KHz

7. Operating temperature:-25 to +125°C

8. Storage temperature: -25 to +85°C
