Low Noise High Current Power Inductors , Shielded SMD Power Inductors

Name: Low Noise High Current Power Inductors , Shielded SMD Power Inductors
Brand: Shinhom
SKU: LPM1240/1250/1260/1265/1270
Price: 1.00 USD
Availability: InStock
Rating: 4.5 (112 reviews)

Large Image : Low Noise High Current Power Inductors , Shielded SMD Power Inductors Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	Shinhom
Certification:	RoHS
Model Number:	LPM1240/1250/1260/1265/1270

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	Carton
Delivery Time:	4~8 Weeks
Payment Terms:	T/T
Supply Ability:	1000000/MONTH

Contact Now

Detailed Product Description

Structure:	Shielded	Installation:	SMT
Pad Size:	13.8*12.8mm	Inductor Value:	Fixed Inductor
Operating Temperature:	-40℃ - +105℃	Storage Temperature:	-40℃ - +105℃
High Light:	high current inductors chokes , smd power choke

LPM1240/1250/1260/1265/1270 Series high current power inductors,Surface Mount choke coil,SMD inductor

FEATURES:

Handles high transient current spikes without saturation.
Ultra low buzz noise, due to composite construction.
Shielded construction
Lowest height in this package footprint.
Lowest DCR/H, in this package size.

APPLCATIONS:

DC/DC converters in distributed power systems
Applications usedin power switching
Personal computers and other handheldelectronic equipment.
PDA/notebook/desktop/server applications
High current POL converters
Low profile, high current power supplies
Battery powered devices

NOTES:·

Test Frequency : 100KHz / 0.25Vdc
Heat Rated Current (Irms) will cause the coil temperature rise approximately,△T=40℃ without core loss.
Saturation Current (Isat) will cause L0 to drop approximately 20%
The part temperature (ambient + temp rise) should not exceed 125℃ under worst case operating conditions. Circuit design, component, PCB trace size and thickness, airflow and other cooling provisions all affect the part temperature. Part temperature should be verified in the end application.
Operating Temperature: -40℃ - +105℃.
Storage Temperature: -40℃ - +105℃.
