Toroidal Qi Wireless Charging Coil Easy Installation RoHS Compliant

Certification
Good quality Current Sense Transformer for sales
Good quality Current Sense Transformer for sales
Very professional and good communication during the cooperation .Product is excellent quality and packaged very well. We will continue to order from shinhom again. Very honest, trustworthy and efficient company to deal with.

—— Alexander

Good products ,good communication ,delivery is on time ,Samples available .

—— Kevin

I'm Online Chat Now

Toroidal Qi Wireless Charging Coil Easy Installation RoHS Compliant

China Toroidal Qi Wireless Charging Coil Easy Installation RoHS Compliant supplier
Toroidal Qi Wireless Charging Coil Easy Installation RoHS Compliant supplier Toroidal Qi Wireless Charging Coil Easy Installation RoHS Compliant supplier Toroidal Qi Wireless Charging Coil Easy Installation RoHS Compliant supplier Toroidal Qi Wireless Charging Coil Easy Installation RoHS Compliant supplier

Large Image :  Toroidal Qi Wireless Charging Coil Easy Installation RoHS Compliant

Product Details:

Place of Origin: China
Brand Name: Shinhom
Certification: RoHS
Model Number: WCA5360-6R3K

Payment & Shipping Terms:

Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Carton
Delivery Time: 4~8 Weeks
Payment Terms: T/T
Supply Ability: 1000000/MONTH
Contact Now
Detailed Product Description
Size: Custom Inductance: 6.3±10%uH
Frequency: 125KHz Resistance: 25mOhm
Rated Current: 13A Operating Temperature: -20℃ To +105℃(Include Temp. Rise 40℃)

 RFID antenna coil/mini toroidal coil,Fast Charging Qi Wireless Charging Coil Wireless Charger Coil Induction Coil





Features:

  • Professional engineer
  • Good after-sale service
  • Qualified material and competative price
  • Winding with self-bonding wire
  • Winding different shapes at your request
  • Meet your inquried inductance and resistance
  • Windings are bonded by a strong adhesive
  • RoHS, SGS, compliant



Electrical specification:

  • Inductance: 6.3uH±10%@125KHz,10mA
  • DCR: 0.025ΩMax
  • Q: 80 Typ.@125KHz
  • Irms: 13.0A Max(Temp. Rise 40℃ Max)
  • Isat: 16A Typ.
  • SRF: 20MHz Ref.
  • Operating temperature: -20℃ to +105℃ (Include temp. Rise 40℃)
  • Storage temperature: -20℃ to +60℃

Toroidal Qi Wireless Charging Coil Easy Installation RoHS Compliant



For More RFID antenna coil, Please Go To Our Website Or Contact Us.

Toroidal Qi Wireless Charging Coil Easy Installation RoHS Compliant
