2000A Rated Input High Current Hall Effect Sensor Epoxy Encapsulated Housing

China 2000A Rated Input High Current Hall Effect Sensor Epoxy Encapsulated Housing supplier
2000A Rated Input High Current Hall Effect Sensor Epoxy Encapsulated Housing supplier 2000A Rated Input High Current Hall Effect Sensor Epoxy Encapsulated Housing supplier

Large Image :  2000A Rated Input High Current Hall Effect Sensor Epoxy Encapsulated Housing

Product Details:

Place of Origin: China
Brand Name: Shinhom
Certification: RoHS
Model Number: HKC-K

Payment & Shipping Terms:

Minimum Order Quantity: 5000PCS
Price: Negotiation
Packaging Details: Carton
Delivery Time: 4~8 Weeks
Payment Terms: T/T
Supply Ability: 1000000/MONTH
Contact Now
Detailed Product Description
Supply Voltage: ±15V±5% Input: 400A-2000A
Output: 4.0V±1% Specification: IEC 6044-1
IP Rating: IP65 Insulation Voltage: 6KV,50Hz,1min

HKC-K Series Closed loop Hall Effect Current Sensor with up to 2000A rated input,Epoxy Encapsulated Housing



           HKC-K series dismountable hall effect current sensor is an open loop device based on the measuring principle of the hall effect, with a galvanic isolation between primary and secondary circuit. It provides accurate electronic measurement of DC, AC or pulsed currents.





Features:

  • Operating currents: 400 to 2000A
  • Rated output voltage: 4V±1%
  • Mount easily
  • High accuracy grade
  • Sensor with a galvanic isolation between primary and secondary circuit
  • Provides accurate electronic measurement of DC, AC or pulsed currents



Directions for use

  •  When the current will be measured goes through a sensor, the voltage will be measured at the output end.(Note: The false wiring may result in the damage of the sensor)
  •  Custom design in the different rated input current and the output voltage are available.





Applications

  • Variable speed drives
  • Welding machine
  • Battery supplied applications
  • Uninterruptible Power Supplies (UPS)
  • Electrochemical



Standards

  1. UL94-V0.
  2. EN60947-1:2004
  3. EC60950-1:2001
  4. EN50178:1998
  5. SJ 20790-2000



ELECTRICAL DATA:

  HKC400K HKC600K HKC800K HKC1000K HKC2000K
Rated input current(IP) 400 600 800 1000 2000 A
Test current range 800 1200 1600 2000 3000 A
Rated output voltage 4±1% V
Supply voltage ±15 ±5% V
Offset voltage ≤±30 ≤±20 mV
Magnetic offset voltage ≤±40 ≤±30 mV
Offset voltage drift ≤±1.5 ≤±1.0 mV/℃
Linearity ≤±1 %FS
Response time ≤7 μS
Insulation voltage(50HZ,1min) 6 KV
Operating Temperature -20~+70
Storage Temperature -40~+85



2000A Rated Input High Current Hall Effect Sensor Epoxy Encapsulated Housing



Notes: Product specifications can be customized
