SMD DC-DC Isolation Transformer GT5030-2W Series with 4000VDC Isolation Voltage, Compact SMD Package, and Toroidal Core Structure

5000
MOQ
SMD DC-DC Isolation Transformer GT5030-2W Series with 4000VDC Isolation Voltage, Compact SMD Package, and Toroidal Core Structure
Features Gallery Product Description Chat Now
Features
Specifications
Isolation Voltage: 4000VDC
Turns Ratio: 1:1:1
Primary Inductance: 250μH
DCR Max: 0.5Ω
Leakage Inductance Max: 25μH
Basic Infomation
Place of Origin: China
Brand Name: SHINHOM
Certification: RoHS/ISO/UL/CE/IATF16949/CNAS
Model Number: GT5030-2W
Document: GT5030-2W Series_.pdf
Payment & Shipping Terms
Delivery Time: 2~8weeks
Payment Terms: L/C,T/T
Product Description
SMD DC-DC Isolation Transformer GT5030-2W Series 4000VDC Isolation Voltage
GT5030-2W Series is a high-performance SMD DC-DC isolation transformer specially designed for power management and isolation applications. Featuring 4000VDC isolation voltage, compact size, and toroidal core structure, it provides stable input/output isolation and reliable signal transmission for industrial and power electronics systems.
Key Features
  • 4000VDC high isolation voltage for enhanced safety
  • Compact SMD package for automated assembly
  • Toroidal core structure with stable performance
  • Wide operating temperature range from -40°C to +125°C
  • Low leakage inductance and excellent coupling efficiency
  • Suitable for industrial power management applications
Product Specifications
Product Series GT5030-2W
Isolation Voltage 4000VDC
Turns Ratio 1:1:1
Primary Inductance 250μH
DCR (Max) 0.5Ω
Leakage Inductance (Max) 25μH
Interwinding Capacitance (Max) 12pF
Peak Current (Max) 400mA
Package Type Tube / Reel
Potting Type Potting / Non-potting
Applications
  • DC-DC converters
  • Industrial control systems
  • Power management modules
  • Communication equipment
  • Medical electronics
  • Isolation power supplies
Competitive Advantages
  • High reliability for industrial environments
  • Excellent isolation performance
  • Compact design saves PCB space
  • Flexible packaging options available
  • Supports customized specifications
