| Core Material | EEL16 |
|---|---|
| Type | High Voltage Ignition Coil |
| Usage | High Frequency |
| Size | 27X18X16mm |
| Turns Ratio | 2700:9:9:3 |
| Type | High Voltage Ignition Coil |
|---|---|
| Alternate | 33% In 3min |
| Input | 6V/12V |
| Power Supply | 220V |
| Size | 63 × 42 × 23mm |
| Core Material | Ferrite Core |
|---|---|
| Inductance Range | Adjustable |
| Type | Trigger Transformer |
| Usage | High Frequency |
| Operating Temperature | -25℃ To +125℃ |
| Name | High Voltage High Frequency Transformer |
|---|---|
| Type | Ignition Coil |
| Usage | High Frequency |
| Frequency | 1KHz -500KHz |
| Potting Compound | Epoxy |
| Core Material | EEL16 |
|---|---|
| Type | High Voltage Ignition Coil |
| Usage | High Frequency |
| Size | 27X18X16mm |
| Turns Ratio | 3000:18 |
| Core Material | Ferrite Core R10*50 |
|---|---|
| Output Voltage | 15KV |
| Type | High Voltage Ignition Coil |
| Usage | High Frequency |
| Size | 53*26*26mm |
| Type | High Voltage Ignition Coil |
|---|---|
| Input | 230V |
| Operating Frequency | 50Hz |
| Size | 82 × 69 × 67mm |
| Ignition Distance | 3 ~ 4mm |
| Core Material | Ferrite Core |
|---|---|
| Output Voltage | 12KV |
| Type | High Voltage Ignition Coil |
| Core | R8X18.5 |
| Size | 31.5*23.2*25.5mm |
| Core Material | Ferrite Core R8*28 |
|---|---|
| Output Voltage | 12KV |
| Type | High Voltage Ignition Coil |
| Usage | High Frequency |
| Size | 30*21*20mm |
| Type | High Voltage Ignition Coil |
|---|---|
| Alternate | 33% In 3min |
| Input | 220V |
| Operating Frequency | 50Hz |
| Size | 92 × 70 × 57mm |
