Toroidal Power Filter Inductor ET24 Filter Coil High Frequency Compact Size

Toroidal Power Filter Inductor ET24 Filter Coil High Frequency Compact Size
Toroidal Power Filter Inductor ET24 Filter Coil High Frequency Compact Size Toroidal Power Filter Inductor ET24 Filter Coil High Frequency Compact Size Toroidal Power Filter Inductor ET24 Filter Coil High Frequency Compact Size Toroidal Power Filter Inductor ET24 Filter Coil High Frequency Compact Size

Large Image :  Toroidal Power Filter Inductor ET24 Filter Coil High Frequency Compact Size Get Best Price

Product Details:
Place of Origin: China
Brand Name: Shinhom
Certification: RoHS
Model Number: ET24 Series
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Carton
Delivery Time: 4~8 Weeks
Payment Terms: T/T
Supply Ability: 1000000/MONTH
Detailed Product Description
Working Frequency: High Frequency Model: Toroidal
Structure Of Magnetizer: Ferrite Coil Nature Of Operation: Coil Filter
Application: Power Supplies Type: Inductor Leaded
High Light:

common mode toroidal chokes

,

common mode power line choke

Customize Common Mode Choke,Power Filter Inductor,ET24 Filter Coil,Common Mode Choke



Features:

  • Compact size, high inductance
  • Excellent frequency characteristics
  • Low magnetic flux leakage
  • Design as Customer's Requested Sepecifications



Application:



  • Filter for switching power supply
  • VCRS,Copy machine,Audio equipment,Game machines;
  • TV sets, Microcomputer equitpmen
  • Communications control equipment
  • Printers,Terminals .
  • high good magnetic shield form itself and slight interferece





TECHNICAL INFORMATION

  • Max operating voltage:250V at 40℃
  • IDC Max: rating AC/DC current A @40℃
  • Hi-Pot 2500V AC winding to winding 3S.
  • Insulation resistance 100MΩ Min DC 500V
  • Temperature Rise Max:40℃
  • Inductance Testing: 10KHz 0.1V HP4284A
  • RDC:QuadTech 1880 Milliohmmeter
  • Surge current Max 10ms: 20X IDC
  • Operating temperature: -40℃ to +105℃
  • Storage Temperature: -40℃ to +105℃



Note: Product specifications can be customized.
