Small Size Electric Encapsulated Power Transformer 2VA Power 50Hz / 60Hz

I'm Online Chat Now
Certification
China Shaanxi Shinhom Enterprise Co.,Ltd certification
China Shaanxi Shinhom Enterprise Co.,Ltd certification
Very professional and good communication during the cooperation .Product is excellent quality and packaged very well. We will continue to order from shinhom again. Very honest, trustworthy and efficient company to deal with.

—— Alexander

Good products ,good communication ,delivery is on time ,Samples available .

—— Kevin

Small Size Electric Encapsulated Power Transformer 2VA Power 50Hz / 60Hz

Small Size Electric Encapsulated Power Transformer 2VA Power 50Hz / 60Hz
Small Size Electric Encapsulated Power Transformer 2VA Power 50Hz / 60Hz Small Size Electric Encapsulated Power Transformer 2VA Power 50Hz / 60Hz Small Size Electric Encapsulated Power Transformer 2VA Power 50Hz / 60Hz

Large Image :  Small Size Electric Encapsulated Power Transformer 2VA Power 50Hz / 60Hz Get Best Price

Product Details:
Place of Origin: China
Brand Name: shinhom
Certification: RoHs
Model Number: PE30
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Carton
Delivery Time: 4-8 weeks
Payment Terms: T/T
Supply Ability: 1000000/month
Detailed Product Description
Input Voltage: 230Vac Output Voltage: 7.5Vac
Power: 2VA Frequency: 50Hz/60Hz
Load Current: 266mA Hi-Pot: 3.6KV
High Light:

linear transformer

,

low frequency transformer

Low frequency transformer encapsulated 7.5v pcb transformer,Epoxy encapsulated transformers





Electrical specification:

  1. Pri Voltage: 230V,50/60Hz
  2. Load sec voltage: 7.5VAC
  3. Load sec current: 266mA
  4. Electric strength: 3600V/AC,10mA,2sec



Characteristics:

  1. acuum epoxy resin encapsulated,100℃/6hours High temperature aging,long woking life 20 years, and with high delectric strength.
  2. Adopt superior quality Silicon steel sheet, with low temperature riseand high efficiency.
  3. PBT Engineering plastics,environmental protection,inflaming retarding Non-defrmation of 120 degrees.
  4. Reasonable structure,convenient installation,low noise,strong earthquake,airtight waterproof,moistureproof.
  5. Work temperature:-30℃~+70℃
  6. Insulation grade:B grade(130℃)
  7. UL94-V0
  8. Dielectric strength:4000V AC/min 5mA





Small Size Electric Encapsulated Power Transformer 2VA Power 50Hz / 60Hz 0







Note: Product specifications can be customized.
