High Voltage Ignition Transformer HTY10-301 for Industrial Combustion and High Power Ignition

The HTY10-301 high-voltage ignition transformer is designed for industrial combustion equipment, high-power boilers, and high-voltage triggering applications. With a turns ratio of 3:300, it delivers a maximum output voltage of 40KV, with an instantaneous power of 200W and continuous operating power of 100W, providing strong ignition energy and fast response. The product features epoxy encapsulation to ensure moisture-proof and vibration-proof performance, suitable for various harsh industrial environments. It is widely used in industrial burners, large boilers, ozone generators, and various high-voltage pulse triggering equipment.

Features

• Turns ratio – 3:300 (1:100)
• Output voltage – up to 40KV
• Instantaneous power – 200W
• Continuous operating power – 100W
• Primary inductance – 3.6µH
• Secondary inductance – 29.3mH
• Operating temperature – -25 to +105°C
• RoHS compliant

Product Specification Selection Table

Applications

• Industrial burner ignition
• Large oil/gas boilers
• Industrial ozone generators
• High-voltage pulse trigger circuits
• Welding equipment high-voltage arc initiation
• Electrostatic precipitators
• Scientific research high-voltage pulse sources
• High-power industrial ignition systems
