High Frequency Transformer

All Products
I'm Online Chat Now
Contact Person : Jack wang
Phone Number : 13909218465
WhatsApp : +8613909218465
71W High Frequency Planar Transformer 200-700 kHz

71W High Frequency Planar Transformer 200-700 kHz

MOQ: 1000
Mounting Type Surface Mount
Power Rating - Max 71W
Operating Temperature -40°C To +125°C
Frequency Range 200 KHz To 700 KHz
Delivery Time 2~8weeks
90W High Frequency Planar Transformer 200-700kHz TP20CS Series

90W High Frequency Planar Transformer 200-700kHz TP20CS Series

MOQ: 1000
Delivery Time 2~8weeks
Payment Terms L/C,T/T
Place of Origin China
Brand Name SHINHOM
Certification RoHS
120W High Frequency Planar Transformer TP20DS Series 200-700kHz

120W High Frequency Planar Transformer TP20DS Series 200-700kHz

MOQ: 1000
Delivery Time 2~8weeks
Payment Terms L/C,T/T
Place of Origin China
Brand Name SHINHOM
Certification RoHS
Gate Drive High FrequencyTransformer GT1011

Gate Drive High FrequencyTransformer GT1011

Price: Negotiation MOQ: Negotiation
Insulation 5000V DC (Hi-Pot Between Pin 3-5, 1mA/60s)
Operating Temperature -40℃ To +75℃
Storage Temperature -40℃ To +85℃
Highlight 1:1 Turns Ratio (3-4):(5-8) ; ≤1μH Max Leakage Inductance (Lk@100kHz) ; 5000V DC Isolation (Pin 3-5) ; Low DCR (≤0.16Ω/winding)
Packaging Details Carton
Photoflash Capacitor Charging Transformer SDRS Series

Photoflash Capacitor Charging Transformer SDRS Series

MOQ: 6000
Insulation 500Vrms Withstand Voltage
Operating Temperature -20°C To +110°C
Highlight Ultra-low Profile (5.8mm Max Height), Minimized Leakage Inductance, Extended Operating Temp (-20°C~110°C), 500Vrms Isolation
Delivery Time 2~8weeks
Payment Terms T/T,L/C
Toroidal SMD Gate Drive Transformer with 4.5KVAC Isolation

Toroidal SMD Gate Drive Transformer with 4.5KVAC Isolation

MOQ: 6000
Operating Frequency 50kHz Or 65kHz
Insulation 4.5KVAC (Pri-Sec), 60s
Storage Temperature +15°C To +25°C, ≤65% RH
Operating Temperature -40°C To +125°C
Output Power Up To 5W
SMD Gate Drive Transformer , Pulse Transformer

SMD Gate Drive Transformer , Pulse Transformer

Price: Negotiation MOQ: 5000PCS
Product Name Pulse Transformer
Installation SMT
Core Material Ferrite Core
Feature High Accuracy
Potting Material No Potting
6.75KV High Insulation Strength Gate Drive Transformer For IGBT

6.75KV High Insulation Strength Gate Drive Transformer For IGBT

Price: Negotiation MOQ: Negotiation
Name Gate Drive Transformer
Product Name High Frequency Transformer
Turns Ratio 1 : 1：1：1
Certification RoHS/SGS/ISO16949
Operating Temperature -40 ℃to +105℃
RoHS / SGS / ISO16949 Pulse Transformers For Broadband PLC System

RoHS / SGS / ISO16949 Pulse Transformers For Broadband PLC System

Price: Negotiation MOQ: Negotiation
Name Pulse Transformer
Product Name Broadband PLC Transformer
Turns Ratio 1 : 1：1
Certification RoHS/SGS/ISO16949
Operating Temperature -20 ℃to +85℃
Smd Gate Drive Transformer , High Frequency Transformer

Smd Gate Drive Transformer , High Frequency Transformer

Price: Negotiation MOQ: 5000PCS
Product Name Pulse Gate Drive Transformer
Installation SMD
Core Material Ferrite
Feature High Accuracy
Potting Material Epoxy Potting
1 2 3 4 5 Next > Last Total 7 page
