Flat Ferrite EMI Filter Bead Large Size Soft Magnetism Ragged Construction

Name: Flat Ferrite EMI Filter Bead Large Size Soft Magnetism Ragged Construction
Brand: Shinhom
SKU: FS19
Price: 1.00 USD
Availability: InStock
Rating: 4.6 (137 reviews)

Large Image : Flat Ferrite EMI Filter Bead Large Size Soft Magnetism Ragged Construction Get Best Price

Product Details:

Place of Origin:	China
Brand Name:	Shinhom
Certification:	RoHS
Model Number:	FS19

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	Carton
Delivery Time:	4~8 Weeks
Payment Terms:	T/T
Supply Ability:	1000000/MONTH

Contact Now

Detailed Product Description

Material:	Ni-Zn	Shape:	Flat
Type:	Soft Ferrite Bead	Composite:	Ferrite Magnet
Size:	196.513.5*12	Customized:	Customized
High Light:	multilayer ferrite chip beads , emi filter bead

FS Large size soft magnetism flat ferrites bead,High frequency EMI Suppression Soft Ferrite Core beads

Features:

High frequency and EMI suppression
Through-hole axial ferrite beads for EMI suppression
Through-hole ferrite beads in ragged construction
Through-hole ferrite beads catering for the measurement of FCC and EMC

Application:

Computer disk drive and PC board to filter the EMI from outside sources such as car radios, mobile phones and VCRs

Electrical characteristics:

SIZE CODE (mm)	A2 FS 196.513.5*12-1.8
at 25 MHz	25Ω MIN
at 100 MHz	73Ω MIN
TEST INSTRUMENTS	HP 4191A
LCR METER	HP 4286
WIRE	0.65T.C.W*100m/m 1/2Ts
TEMPERATURE	15℃ to 35℃
HUMIDITY	25% to 85% RH
