10uH Class D Amplifier Power Inductor For SMD Digital Power

5000PCS
MOQ
Negotiation
Price
10uH Class D Amplifier Power Inductor For SMD Digital Power
Features Gallery Product Description Request A Quote
Features
Specifications
Current Range: Up To 15A
Inductance Range: 10uH To 22uH
Application: Digital Power Amplifier
Installation: Lead Inductor
Storage Temperature: -40℃ To +125℃
Operating Temperature: -40℃ To +180℃(ambient Plus Self-temperature Rise)
Highlight:

10uH High Power Inductor

,

Class D Multilayer Power Inductor

,

Digital SMD Power Inductor
Basic Infomation
Place of Origin: China
Brand Name: Shinhom
Certification: RoHS
Model Number: HDE1219/HDE1623
Payment & Shipping Terms
Packaging Details: Carton
Delivery Time: 4~8 Weeks
Payment Terms: T/T
Supply Ability: 1000000/MONTH
Product Description

Power Inductor For Class-D Amplifier , Inductor For Digital Power Amplifier



APPLCATIONS:

  • Suitable as choke digit al amp,Car audio,LCD and PDP TV,5.1ch Home theater,etc.



FEATURES:

  • Exceelent weldability and resistancd
  • Low radiation noise by special magnetically sheilded structrue
  • Low resistance,high current
  • Wide frequency range
  • The optimal design realizes high quality sound and low distortion

10uH Class D Amplifier Power Inductor For SMD Digital Power 0



Notes:

  • Test Frequency : 100KHz / 0.25Vdc@25℃
  • Heat Rated Current (Irms) will cause the coil temperature rise
  • Heat rating current : A rise in temperature of core surface is within 40℃
  • DC saturation allowable current: Value of inductance decrease within -25%
  • Operating Temperature & Storage Temperature: -25℃~105℃





Note: Product specifications can be customized.



Tag:

smd power choke

high current inductors chokes

low profile high current inductor
