Shielded SMD Power Inductor SPI0402S Series with High Current Capability and Compact Design for DC-DC Converters

5000
MOQ
Shielded SMD Power Inductor SPI0402S Series with High Current Capability and Compact Design for DC-DC Converters
Features Gallery Product Description Chat Now
Features
Specifications
Inductance Range: 1.0µH To 10mH
Current Rating: Up To 3A
DC Resistance: As Low As 0.040Ω
Operating Temperature: -40°C To +85°C
Mounting Type: Surface Mount (SMD)
Basic Infomation
Place of Origin: China
Brand Name: SHINHOM
Certification: RoHS/ISO/UL/CE/IATF16949/CNAS
Model Number: SPI0402S
Document: SPI0402S_.pdf
Payment & Shipping Terms
Delivery Time: 2~8weeks
Payment Terms: L/C,T/T
Product Description
Shielded SMD Power Inductor SPI0402S Series for DC-DC Converters
The SPI0402S Series Shielded SMD Power Inductor is designed for compact electronic devices requiring high efficiency, stable performance, and reliable current handling. With a small footprint and flat-top design, this inductor is ideal for automated assembly and high-density PCB layouts, making it widely used in modern portable and power management applications.
Key Features
  • Shielded structure for reduced EMI interference
  • Compact SMD design for space-saving applications
  • High current capability up to 3A
  • Low DC resistance for improved efficiency
  • Flat-top design for automatic pick & place
  • Wide inductance range for flexible circuit design
Technical Specifications
Parameter Specification
Inductance Range 1.0µH to 10mH
Current Rating Up to 3A
DC Resistance As low as 0.040Ω
Tolerance ±20%
Operating Temperature -40°C to +85°C
Storage Temperature -40°C to +105°C
Mounting Type Surface Mount (SMD)
Shielding Yes
Soldering Reflow compatible
Applications
  • DC-DC converters (step-up / step-down)
  • Laptops and portable devices
  • PDA and flash memory modules
  • Power management circuits
  • Consumer electronics
  • Industrial control systems
