This planar transformer is designed for DC/DC and DC/AC conversion applications. It features a low-profile structure, with power up to 3000W and current up to 73A. The pad size is 23.5mm × 19.5mm.The product offers ultra-low leakage inductance (<0.2%), high power density (5W-25kW per component), and low EMI radiation.
Multiple core sizes are available from EE14 to EE100. It supports horizontal/vertical mounting, through-hole/SMT, and pin/fly lead termination and mounting options, compatible with all SMPS topologies.
It is widely used in high-density DC/DC power supplies, telecom equipment, industrial control systems, and automotive and heavy-duty vehicle systems.
FEATURES:
- Low-profile planar transformer
- High-power planar transformer
- High-frequency planar transformer
- PCB planar transformer
- Planar switching power transformer
- EE14/EE16/ EE18/EE22/EE32/EE38/EE43/EE64/EE100 planartransformer
- Off the shelf SMT planar transformer
- Power range: up to 3000W
- Very low Leakage Inductance (less than 0.2% for un-gapped cores).
- Cost effective and competitive prices.
- Minimum Electromagnetic Interference (EMI).
- High specific power density (5W-25kW per one component).
- High Creepage and Clearance distances between primary and
- Applicable to all SMPS topologies.
- Various mounting and terminals options (Horizontal, Vertical, Through-holes, SMT, Pins, Flying-cables and more).
- Specially designed heat-dissipating Clasps.
APPLICATIONS:
- High density and high energy efficiency.
- High current DC/DC power supplies high current.
- The main windings inductor serves as an output choke,
- While the auxiliary windings controls, Input current to the PM(TI25S1604).
- Telecommunications, industrial control systems,
- Automotive and heavy equipment vehicle systems
TECHNICAL INFORMATION:
- Inductance of PE 20s1604 measured on Agilient/HP4284 between pins 7 & 11 at 100kHz, 0.1 Vrms.
- The IDC rated is either 85% of the IDC saturation or the IDC heating depending which is lower.
- The IDC saturation is the current which causes the inductance to drop by 15% of its nominal value.
- The IDC heating is the current which causes the temperature of the part to increase by approximately 45℃.
FAQ
Q: What are the advantages of planar transformers compared to traditional wire-wound transformers?
A: Planar transformers use a low-profile structure and PCB-style winding design. They offer ultra-low leakage inductance (<0.2%), high power density (5W-25kW per component), low EMI radiation, and excellent thermal management. The low-profile design also significantly reduces height, making it suitable for high-density mounting applications.
Q: What are the advantages of ultra-low leakage inductance (<0.2%)?
A: Ultra-low leakage inductance reduces voltage spikes on switching devices, lowers switching losses, and improves system efficiency. It also reduces electromagnetic interference (EMI) to surrounding circuits, simplifying EMI filter design.
Q: How long is the delivery time and what packaging methods are used?
A: The standard lead time is 2-8 weeks after order confirmation, depending on product specifications and order quantity. Products are securely packed with cartons, foam, pallets, wrapping film, and fixing straps to ensure safe international transportation.
