High Dielectric Strength Encapsulated Transformer for Industrial Equipment

This potted power transformer is manufactured using vacuum epoxy resin potting and a toroidal coil structure, specifically designed for medical equipment and industrial equipment, ensuring high dielectric strength, high-density mounting, and good shielding quality.The product features a robust and reliable structure and complies with EN61558 and EN60950 standards and CE certification requirements.It is suitable for medical equipment, industrial equipment, and communication equipment. It is an ideal choice for potted power transformer applications in power conversion and electronic equipment.

Features

• High dielectric strength potted transformer
• Multiple voltage options
• Frequency – 50/60Hz
• Supply voltage – 115V to 230V
• Vacuum potting
• Dielectric strength – 4000Vrms
• Complies with UL94V-0 flame retardant standard
• Power range – 0.35W to 40W

Applications

• Medical equipment
• Industrial equipment
• Test equipment
• Communication equipment
• Alarm systems
• Power supplies
• Electronic equipment
• Instruments and meters

Electrical specification:

• Pri voltage: 230V±10%
• Output: 12V,2.5A
• Operating frequency: 50/60Hz
• No-load loss: 1.5W Max
• Insulation class: B
• Power: 30VA
• Voltage regulation: 11%Max
• Temperature rise: 28℃ Max
• Hi-Pot: 3500Vac,1min,5mA Pri to Sec
• Operating temperature: -30℃ to +50℃
