Customized Dip Power Inductor , Ferrite Rod Core Inductor Inductive Choke

Customized Dip Power Inductor , Ferrite Rod Core Inductor Inductive Choke
Customized Dip Power Inductor , Ferrite Rod Core Inductor Inductive Choke Customized Dip Power Inductor , Ferrite Rod Core Inductor Inductive Choke Customized Dip Power Inductor , Ferrite Rod Core Inductor Inductive Choke Customized Dip Power Inductor , Ferrite Rod Core Inductor Inductive Choke

Large Image :  Customized Dip Power Inductor , Ferrite Rod Core Inductor Inductive Choke Get Best Price

Product Details:
Place of Origin: China
Brand Name: Shinhom
Certification: RoHS
Model Number: RC Series
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Carton
Delivery Time: 4~8 Weeks
Payment Terms: T/T
Supply Ability: 1000000/MONTH
Detailed Product Description
Type: Ferrite Rod Inductors, Ferrite Bar Inductor Operating Temperature: -40℃ To +105℃
Size: 0709/0809/1112/1315 Customized: Customized
Structure: Inductive Choke Inductor Value: Fixed Inductor
High Light:

leaded power inductor

,

through hole inductor

RC Series Through hole DIP inductor,Leaded Inductor,Rod Core choke coil,Vertical and horizontal DIP choke



Features:

  • High Saturation Material
  • Polyolefin Shrink Tubing
  • Low DC Resistance
  • High Reliability Low cost



Applications:

  • Switching Regulators
  • RFI Suppression Filters
  • SCR and TRIAC Controls
  • Automotive Systems



Electrical specification​:

  • Testing: (Equivalent acceptable) lnductance:HP4284A
  • RDC:QuadTech 1880 Milliohmmeter
  • Q- HP4342A - SRF-HP4191A
  • IDC Max is decreased 10% against its initial value
  • Operating temperature: -40℃ to +105℃
  • Storage Temperature: -40℃ to +105℃
  • Solder methods: Vapor Phase,Infrared Reflow
  • Resistance to soldering heat:260℃ for 10 seconds



Prat no. Core diameter Core height inductance I(sat)
RC0312 3.0 12.0 1-6uH 4.5-10A

RC0315

3.0 15.0 2.0-10uH 3.2-6.5A
RC0415 4.0 15.0 1.2-7.2uH 5.8-16.5A
RC0515 5.0 15.0 2-10uH 8.5-18A
RC0520 5.0 20.0 2.2-15uH 5.8-15A
RC0525 5.0 25.0 4.7-22uH 4.5-11.5A
RC0615 6.0 15.0 1-22uH 7.5-24A
RC0620 6.0 20.0 2-15uH 8.5-21A
RC0625 6.0 25.0 3-22uH 8.0-20A
RC0630 6.0 30.0 4.5-22uH 7.5-16.5A



Vertical or horizontal can be customized

Customized Dip Power Inductor , Ferrite Rod Core Inductor Inductive Choke 0Customized Dip Power Inductor , Ferrite Rod Core Inductor Inductive Choke 1



Note: Product specifications can be customized.
