EFD25 SMD Current Sensing Transformers High Frequency

EFD25 SMD Current Sensing Transformers High Frequency
EFD25 SMD Current Sensing Transformers High Frequency EFD25 SMD Current Sensing Transformers High Frequency EFD25 SMD Current Sensing Transformers High Frequency

Large Image :  EFD25 SMD Current Sensing Transformers High Frequency Get Best Price

Product Details:
Place of Origin: China
Brand Name: Shinhom
Certification: RoHS
Model Number: ACSTE25 Series
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Carton
Delivery Time: 4~8 Weeks
Payment Terms: T/T
Supply Ability: 1000000/MONTH
Detailed Product Description
Turns: 20 To 150Ts Installation: SMD
Insulation Voltage: 1500Vac Frequency Range: Up To 1MHz
Sensed Current: Up To 20A Operating Temperature: -40℃ To 125℃
High Light:

20A Current Sense Transformer

,

SMD Current Transformers

,

EFD25 Current Transformers

EE4.6 SMD High frequency Current Sensing Transformers , SMD Current transformers



Feature:

  • Turns Ratio: 1:100  1:150 1:200 available
  • Sensed current up to 50 Amps
  • Designed for use up to 500KHz and above
  • Very low primary resistance
  • High frequency current transformers for SMPS appllications
  • High-permeability ferrite current transformers
  • Low-profile current transformers
  • PCB mount current transformers
  • Reliable linear performance transformers



Applications:

  • Continuous AC current monitoring in switched-mode power supply
  • Overload and short-circuit protection
  • Current measurement in traction motor and battery management systems in conventional and xEV (EV, HEV, FCEV) vehicles.
  • Can also be used in 48 V vehicle electrical systems.


Notes:

  • Primary current of 50 A causes 40℃ temperature rise from 25℃ ambient. Higher current causes a greater temperature rise
  • Operating temperature : -55℃ to 125℃
  • Storage temperature Component: -40℃ to +105℃
  • Tape and reel packaging: -40℃ to +80℃
  • Moisture sensitivity level(MSL) 1 (Unlimited floor life at <30deg /85% relative humidity)
  • Inductance measured between secondary pins at 100kHz, 0.1 Vrms, 0 Adc
  • Frequency range: 50KHz to 500KHz
  • Inductance measured at 0Adc on HP 4284A LCR Meter or equivalent
  • DCR measured on Chroma 16502 micro-ohmmeter or equivalent

EFD25 SMD Current Sensing Transformers High Frequency 0







Notes: Product specifications can be customized
