FEATURES:
·High current rating
·Hing frequency range up to 1.0MHZ
·Very low DC resistance
·Shielded construction
·All series of product are Halogen-free and
·ROHS compliant
APPLICATIONS:
· Motherboards for laptop and desktop computers
· DC/DC converter in distributed power systems or VRM applications
· Inductor for general purpose use
| Series | Inductance | Rated current |
| 0808A | 0.1~4.7uH | 8.0~29.0A |
|
0808B |
0.27~4.7uH | 8.0~27.5A |
| 1009A | 10.0~33.0uH | 4.5~7.0A |
| 1211A | 10.0~22.0uH | 10.0~12.0A |
| 1010B | 0.15~2.2uH | 17.0~45.0A |
| 1109B | 0.25~2.2uH | 16.5~36.0A |
| 1111B | 0.25~3.3uH | 12.0~42.0A |
| 1210A | 0.22~8.2uH | 8.5~38.0A |
| 1312B | 0.22~2.2uH | 18.0~45.0A |
| 1315A | 0.33~47.0uH | 4.5~37.0A |
| 1616A | 22.0~100.0uH | 8.0~13.0A |
| 1818A | 3.3~33.0uH | 9.5~17.0A |
| 2222A | 120.0uH | 7.0A |
| 2828A | 200.0~250.0uH | 8.5~12.0A |
| 3333A | 33.0uH | 20.0A |
Note: Product specifications can be customized.
