SWAC0512W 5W AC-DC Converter

Engineered for reliable power conversion in compact applications, the SWAC0512W AC-DC Converter delivers stable 5W output in an efficient DIP package design. Featuring wide voltage input capability and robust thermal performance, this power supply module maintains precise voltage regulation across varying load conditions while operating in industrial temperature environments. The integrated circuit design requires no additional components for basic operation, providing a simplified solution for space-constrained applications demanding consistent power delivery.

Features:

• Output Power: 5W
• Input Voltage Range: 85-265VAC
• Output Voltage: 12V
• Output Current: 0.425A
• Efficiency: Up to 83.5% @220VAC full load
• Operating Temperature: -20°C to +85°C
• Ripple & Noise: 100mVp-p maximum
• Load Regulation: ±1% (10%-100% load)
• Line Regulation: ±0.5% maximum
• Short Circuit Protection: Sustainable with self-recovery
• Switching Frequency: 100-300kHz
• MTBF: 3,500,000 hours @25°C
• Package: DIP standard pin configuration
• Cooling: Natural convection
• Compliance: RoHS directive

Applications

• Industrial Control Systems: Power supply for PLCs, sensor interfaces and control circuits requiring reliable 5W conversion in compact DIP packages.
• Consumer Electronics: Home automation devices, smart appliances and digital displays needing wide input voltage compatibility with stable 12V output.
• Embedded Computing: Board-level power applications where space optimization and consistent performance are critical design factors.
• Test & Measurement: Precision instruments and monitoring equipment requiring clean power with minimal ripple interference.
• Telecommunications: Network accessories and communication modules operating in varied voltage environments with limited space availability.
• Automotive Electronics: In-vehicle systems and accessories demanding robust performance across industrial temperature ranges.
