Bi-Directional Couplers

Overview

Our Bi-Directional Couplers are precision RF passive components designed to enable accurate sampling of both forward and reflected signals in RF and microwave systems. These couplers allow simultaneous measurement of incident and reflected power, making them ideal for system monitoring, VSWR testing, and power sampling in communication and test applications.

Constructed with microstrip design and high-quality materials, our bi-directional couplers deliver low insertion loss, high isolation, and excellent coupling flatness across wide operating bands—ensuring reliable performance in demanding environments.

Key Features

Accurate Bidirectional Coupling: Precisely samples both forward and reflected paths for reliable measurements.
Low Insertion Loss: Minimizes loss in the main signal path for high-efficiency systems.
Wide Operating Band: Supports broad frequency ranges suitable for various RF applications.
High Isolation & Flatness: Ensures strong isolation between ports and stable coupling response.
Low VSWR: Maintains impedance matching and low reflection across the band.
Compact Microstrip Design: Saves space and is easy to integrate into modern PCBs.
Customization Available: Coupling factor, frequency range, connector type, and housing can be tailored.

Applications

VSWR and Power Monitoring: Accurate forward/reflected power analysis in transmitters and receivers.
Signal Sampling: Extract small portions of RF energy without interrupting main signal flow.
Test and Measurement Systems: Calibration and performance verification in RF test setups.
Telecommunications: Monitoring system performance in wireless and wired RF links.
Antenna and Network Analysis: Impedance and reflection characterization in antenna systems.

Why Choose Our Bi-Directional Couplers?

Precision Signal Monitoring: Sampling forward and reflected power with high accuracy.
Efficient RF Performance: Low loss and stable VSWR for reliable system operation.
Flexible Customization: Tailored options for coupling factor, frequency band, and connectors.
Broad Application Compatibility: Suitable for communications, test equipment, and system monitoring across RF and microwave domains.
