SMD Chip Inductor and Ferrite Bead with 1µH to 100µH Inductance, Low DC Resistance, and High Current Capability

5000
MOQ
SMD Chip Inductor and Ferrite Bead with 1µH to 100µH Inductance, Low DC Resistance, and High Current Capability
Features Gallery Product Description Chat Now
Features
Specifications
Package Sizes: 0402 / 0603 / 0805 / 1008 / 1206
Inductance Range: 1µH To 100µH
Tolerance: ±20%
Test Condition: 100kHz, 0.1Vrms
Operating Temperature: -40°C To +105°C
Basic Infomation
Place of Origin: China
Brand Name: SHINHOM
Certification: RoHS/ISO/UL/CE/IATF16949/CNAS
Model Number: Shinhom-20108821-#9131
Payment & Shipping Terms
Delivery Time: 2~8weeks
Payment Terms: L/C,T/T
Product Description
SMD Chip Inductor and Chip Beads with Inductance Ranging from 1 to 100uH
Our SMD Chip Inductors and Ferrite Beads are designed for compact electronic circuits requiring stable inductance, low DC resistance, and high current capability. Available in multiple industry-standard package sizes — 0402, 0603, 0805, 1008, and 1206 — these components are ideal for high-density PCB designs and automated SMT assembly. With an inductance range from 1 µH to 100µH (±20%), they provide reliable performance in DC/DC converters, battery-powered devices, and portable electronics.
Key Specifications
Package Sizes 0402 / 0603 / 0805 / 1008 / 1206
Inductance Range 1µH to 100µH
Tolerance ±20% (M)
Test Condition 100kHz, 0.1Vrms
DC Current Rating Inductance drop 10% from initial value (typical)
Operating Temperature -40°C to +105°C
Mounting Type Surface-mount (SMD/SMT)
Electrical Characteristics Measured at 25°C
Product Features
  • Low DCR Design: Optimized internal winding structure ensures very low DC resistance, minimizing power loss and improving circuit efficiency.
  • High Current Capability: Suitable for high-current applications such as DC/DC converters and power management modules.
  • Magnetically Shielded Options: Shielded structures help reduce EMI and magnetic interference in high-density PCB layouts.
  • Reliable Soldering Performance: Compatible with reflow soldering and hand soldering processes. Strong solder fillets and clear marking prevent damage during assembly.
  • Equivalent to Leading Brands: Comparable in performance to products from Coilcraft, Toko, Sumida, TDK, and Murata.
Typical Applications
  • DC/DC converters
  • Notebook computers
  • Battery-powered equipment
  • Digital cameras and scanners
  • CD-ROM / DVD devices
  • PDA and portable electronics
Why Choose Our SMD Chip Inductors?
  • Wide size range (0402-1206)
  • 1-100µH inductance coverage
  • Low DCR & high efficiency
  • High current handling
  • Stable performance over wide temperature range
  • Suitable for automated SMT production
