Low Profile SMD Inductor with 1 to 1,200nH Inductance and Large Current Capability for Compact PCB Layouts

5000
MOQ
Low Profile SMD Inductor with 1 to 1,200nH Inductance and Large Current Capability for Compact PCB Layouts
Features Gallery Product Description Chat Now
Features
Specifications
Inductance Range: 1 To 1,200 NH
Current Capability: Large
Profile Design: Low-profile
Operating Temperature: -20 To 85°C
Insulation Resistance: >100 MΩ
Basic Infomation
Place of Origin: China
Brand Name: SHINHOM
Certification: RoHS/ISO/UL/CE/IATF16949/CNAS
Model Number: AIML
Payment & Shipping Terms
Delivery Time: 2~8weeks
Payment Terms: L/C,T/T
Product Description
Chip Inductor with 1 to 1,200nH Inductance, Low Profile and Large Current
Product Overview

The Low-Profile Chip Inductor is a high-efficiency, magnetically shielded SMD component designed for high-current applications in compact PCB layouts. With low DCR and a shielded construction, it ensures minimal power loss, high reliability, and strong performance in space-constrained environments.

Featuring an inductance range from 1 to 1,200 nH, this SMD inductor supports a wide variety of power applications while maintaining stable operation across temperature and humidity variations.

Key Features
Inductance Range
1 to 1,200 nH, supporting versatile power designs
High Current Capability
Handles large currents in SMD power applications
Low-Profile Design
Ideal for compact and space-conscious PCB layouts
Magnetic Shielding
Reduces EMI interference and preserves signal integrity
Low Resistance
Minimizes deep power losses for efficient performance
Operating Temperature
-20 to 85°C (with heating coil)
Durability
Terminal strength verified after soldering; withstands vibration, humidity, and reflow soldering conditions
Safety
Dielectric strength tested at 100V DC; insulation resistance >100 MΩ
Applications
  • SMD power management circuits
  • Compact DC/DC converters and embedded systems
  • High-current surface-mount power designs
  • Automotive and industrial electronics requiring robust SMD inductors
