The ERL28 ferrite high-frequency flyback transformer is designed for switching power supply and DC-DC converter applications, with efficiency up to 95%. It offers high isolation strength, low-profile design, and lightweight advantages. The product uses an ERL28 ferrite core, offering strong anti-interference capability, low distributed capacitance, and low transmission attenuation. The structure is robust and reliable. Inductance is fine-tunable, suitable for high-density mounting and good shielding applications. Multiple core series are also available, including PQ, EI, EE, EF, ETD, EFD, and RM, with custom design support for customer requirements. It is widely used in switching power supplies, chargers, alarm systems, TV/CRT monitors, UPS, VCD/DVD players, audio/video equipment, OA equipment, inverters, fax switching systems, and wave carrier filters.
Features
- Custom designs available
- High efficiency of over 95%
- High isolation strength
- Lower profile and weight
- High power density
- PQ Series: PQ2020, PQ2016, PQ2625, PQ3230, PQ3535, PQ4040 and PQ5050
- EI series: EI19, EI28, EI33, EI40
- EE series : EE5.0, EE8.3, EE10, EE13, EE16, EE19, EE22, EE25, EE28, EE30, EE33, EE35, EE40, EE42, EE50, EE55, EE65,EE70
- EF series: EF16, EF20, EF25 and EF32
- ERL series: ERL-28, ERL-35, ERL-39, ERL-42 and ERL-49
- ETD series: ETD29, ETD34, ETD39, ETD44, ETD49, ETD54 and ETD59
- EFD series: EFD15, EFD20, EFD25 and EFD30
- RM series: RM-4, RM-5, RM-6, RM-8, RM-10, RM-12 and RM-14
Applications
- Switching power supplies (SMPS)
- Battery chargers
- Alarm systems
- TV/CRT monitor power supplies
- UPS uninterruptible power supplies
- VCD/DVD player power supplies
- Audio/video equipment and OA equipment
- Inverters and fax switching systems
ABOUT US:
Shinhom Enterprise was founded in Xi'an China with nearly 20 years of experiencing of designing & manufacturing transformers & Coils components.
High quality, low cost and best service are what we pursuit most!
Meanwhile, the certification of ISO 9001 by SGS system was also earned.
Shinhom is to remain a specialist in designing and manufacturing high-performance transformers,power inductors, choke coils power supplies for purchasers around the world.
FAQ
Q: Which topologies does this product support?
A: This transformer supports half-bridge and full-bridge SMPS topologies. It is also suitable for flyback power supply designs. Inductance is fine-tunable, adapting to various power conversion requirements.
Q: Which core series are available for customisation?
A: Multiple core series are available for customisation, including PQ, EI, EE, EF, ERL, ETD, EFD, and RM. These cover applications from low-power signal transformers to high-power switching power supplies.
Q: What are the advantages of the low-profile design?
A: The low-profile design reduces transformer height, saves PCB vertical space, and is suitable for thin power supply designs and space-constrained applications, while also reducing weight.
Q: How to apply for samples? What is the lead time?
A: You can submit a sample application through our website or email. Please provide your company information and target specifications (including core type, power, and output voltage requirements). Custom sample lead time is generally 7-10 working days. Mass order lead time is generally 2-8 weeks.
