High Accuracy Split-Core CT SCTK660B Series for Data Logging

Negotiation
MOQ
Negotiation
Price
High Accuracy Split-Core CT SCTK660B Series for Data Logging
Features Gallery Product Description Chat Now
Features
Specifications
Current Range: 0.5~1000A
Output: 0-500mA Or 0.333V(AC)
Class: 0.2、0.5、1.0
Installation: Busbar Type
Magnetic Circuit Structure: Combined Type
Customizable: Yes
Highlight:

High accuracy split-core CT

,

Split-core current transformer for data logging

,

SCTK660B series current transformer
Basic Infomation
Place of Origin: China
Brand Name: Shinhom
Certification: RoHS
Model Number: SCTK660B Series
Payment & Shipping Terms
Packaging Details: Carton
Delivery Time: 4~8 Weeks
Payment Terms: T/T
Supply Ability: 10000/MONTH
Product Description

The SCTK660B series split-core current transformer is designed for power monitoring, energy management, and retrofit projects. The product uses a flip-open split-core structure that allows quick installation without disconnecting cables, making it especially suitable for retrofit projects and online installation scenarios.It offers high-precision measurement. Isolation voltage is 3KV/60 seconds. The flame-retardant housing meets UL94V-0 standards. Maximum working voltage is AC600V.It is widely used in data logging, power monitoring, energy management, new energy monitoring, and cost allocation applications.

Features
  • High accuracy at 10-130% of rated current
  • AC isolation resistance: 3KV for 60s
  • Swing open for ease of installation
  • Rigid housing case with UL® 94V-0 durable plastic
  • Safety standard: IEC/EN60044-1
  • Nominal phase angle error and
  • Nominal linearity error: Conform IEC61869-2
  • ConformIEC60044-1
  • Max.operation voltage: AC600V
Applications
  • Data logging
  • Power monitoring
  • Energy management
  • New energy monitoring
  • Cost allocation
  • Power distribution systems
  • Retrofit projects (online installation)
  • Industrial automation control
Electrical Parameter
Frequency 50-2.5KHz
Rated Input 0.5A-1000A
Measuring range 10%In-130%In
Rated Output 0.333V(AC) or 0-5A
Ratio ≤± 0.2％
Phase angle ≤ ±10min
Dielectric strength 5.0KV/1mA/1min
Insulation Resistance DC500V/100MΩmin
Mechanical Parameter
Case PC/UL94-V0
Bobbin PBT
Core Permalloy
Internal structure Epoxy
Construction Tie
Operating Temp －25℃～＋75℃
Operating Humidity ≤85%
Output Connection Terminal or UL1015 22AWG Wire 1.5m
Type selection
P/N Rated Input (A) Output (mA/V) Accuracy Dimensions(mm)
A B C D E F
SCTK660B-010 0.5-100A 0.333V/0-50mA 0.2,0.5,1.0 57.6 50.0 22.0 5.0 16.7 25.0
SCTK660B-019 1-250A 0.333V/0-100mA/1A 0.2,0.5,1.0 66.6 59.0 22.0 9.5 25.7 29.5
SCTK660B-025 5-400A 0.333V/0-200mA/1A/5A 0.2,0.5,1.0 73.1 65.0 22.0 12.5 31.7 32.5
SCTK660B-032 5-630A 0.333V/0-200mA/1A/5A 0.2,0.5,1.0 82.1 74.0 22.0 16.0 38.7 37.0
SCTK660B-045 5-1000A 0.333V/0-500mA/1A/5A 0.2,0.5,1.0 95.1 87.0 22.0 22.5 53.7 43.5

High Accuracy Split-Core CT SCTK660B Series for Data Logging

High Accuracy Split-Core CT SCTK660B Series for Data Logging

Notes: Product specifications can be customized

FAQ

Q: Does the split-core current transformer require power-off during installation?

A: No. The SCTK660B series uses a flip-open structure with a core that opens and closes. It can be installed without disconnecting or removing any cables. It is especially suitable for retrofit projects and applications where power cannot be turned off.

Q: What is the significance of the UL94V-0 flame-retardant housing?

A: UL94V-0 is one of the highest standards for plastic material flame retardancy. It ensures the sensor housing is not easily ignitable under abnormal conditions, meeting the safety requirements of industrial equipment.

Q: How to apply for samples? What is the lead time?

A: You can submit a sample application through our website or email. Please provide your company information and target model. Samples are free of charge and will be shipped within 3-5 working days. Mass order lead time is generally 2-8 weeks.
