Name: Common Mode Inductance SQ2516-6R8Y for SMPS and Communication Equipment EMI Filtering
Brand: Shaanxi Shinhom Enterprise Co.,Ltd
SKU: SQ2516-6R8Y
Availability: InStock

Features Gallery Product Description Chat Now

Features

Specifications

Customized: Support

Height: 5.3 Mm

Mount: Surface Mount

Shape: Round, Flat

Feature: Low Core Loss

Smd Or Tht: Both Available

Working Frequency: 50/60Hz

Basic Infomation

Place of Origin: China

Brand Name: Shinhom

Certification: RoHS/ISO/UL/CE/IATF16949/CNAS

Model Number: SQ2516-6R8Y

Document: SQ2516-6R8Y.pdf

Payment & Shipping Terms

Delivery Time: 2~8weeks

Payment Terms: L/C,T/T

Gallery

Common Mode Inductance SQ2516-6R8Y for SMPS and Communication Equipment EMI Filtering

Product Description

The SQ2516-6R8Y common-mode inductor is designed for common-mode noise suppression in AC/DC and DC/DC power lines, offering excellent common-mode noise attenuation performance. The product uses an SMD package, compatible with automated SMT production lines. Both common-mode and differential-mode characteristics are optimised to ensure stable filtering performance across a wide frequency range. It is widely used in switching power supplies, communication equipment, industrial control, automotive electronics, and various power line EMI filtering applications.

Features

Excellent common-mode noise suppression performance
Suitable for AC/DC and DC/DC converters
Low DCR
High current carrying capacity
High common-mode impedance at high frequencies
Wide operating temperature range
SMD package – suitable for automated SMT placement
RoHS compliant

Applications

AC/DC power line filtering
DC/DC converter noise suppression
Switching power supply (SMPS) EMI filtering
Communication equipment power supplies
Industrial control equipment
Automotive electronic systems
Computer peripheral power supplies
EMI/RFI suppression

FAQ

Q: What package does the SQ2516-6R8Y use?

A: This product uses an SMD (surface mount) package, compatible with automated SMT production lines and reflow soldering processes.

Q: How to apply for samples?

A: You can submit a sample application through our website or email. Please provide your company information and target model. Samples are free of charge and will be shipped within 3-5 working days.

Q: What is the minimum order quantity (MOQ)?

A: The MOQ for standard models is 1000 pieces. For small trial orders, lower quantities can be negotiated. Please contact our sales team for details.
