Lan Magnetics Module Lan-100 Series For Switches And Routers

5000PCS
MOQ
Negotiation
Price
Lan Magnetics Module Lan-100 Series For Switches And Routers
Features Gallery Product Description Chat Now
Features
Specifications
Name: SMT LAN Transformer
Range Of Application: Choke
Transport Package: Tape & Reel
Feature: Fire/Flame Retardant
Specification: 10/100base-t Single Port
Operating Temperature: 0 ~ 70℃
Highlight:

LAN transformer module for switches

,

LAN-100 series magnetic module

,

Ethernet LAN transformer for routers
Basic Infomation
Place of Origin: China
Brand Name: Shinhom
Certification: RoHS
Model Number: LAN-100
Payment & Shipping Terms
Packaging Details: Carton
Delivery Time: 4~8 Weeks
Payment Terms: T/T
Supply Ability: 1000000/MONTH
Product Description

LAN-100 Seires 10/100Base-T Magnetics modules,Power/Circuit SMD Ethernet Single Port Lan Magnetic Transformer

The LAN-100 series 10/100Base-T Ethernet magnetic module is designed for network interface applications, complying with IEEE802.3 and ANSI X3.263 standards. The product offers both SMT and THT package options, with a miniature size that saves PCB space. Open-circuit inductance: 350µH minimum (@8mA bias). Isolation voltage: 1500VRMS. Insertion loss: ≤1.1-1.2dB. It offers excellent return loss, crosstalk, and common-mode rejection performance. It is widely used in switches, routers, network interface cards, PoE power supply devices, and various network communication equipment.

FEATURES

  • IEEE 802.3,ANSI X3.263
  • SMT & Thru Hole available
  • Miniature size
  • Primary OCL Tx & Rx: 350μH Min @ Idc=8mA
  • Hipot : 1500 VRMS
  • Soldering methods:Wave,Reflow
  • Operating Temperature:0℃ to 70℃
  • Storage Temperature:-55℃ to 125℃

Applications

  • 10/100Base-T Ethernet switches
  • Network routers
  • Network Interface Cards (NIC)
  • PoE power supply devices
  • Network cameras
  • Wireless Access Points (AP)
  • Industrial Ethernet equipment
  • Embedded network modules
Lan Magnetics Module Lan-100 Series For Switches And Routers

FAQ

Q: How to choose between SMT and THT packages?

A: SMT (surface mount) is suitable for automated SMT production lines, ideal for high-volume production and high-density PCB designs. THT (through-hole) is suitable for wave soldering, allowing easy manual soldering and prototyping. Please choose based on your production process.

Q: What is the insertion loss performance of this product?

A: Insertion loss is ≤1.1-1.2dB (1-100MHz) . Low insertion loss ensures efficient signal transmission, reduces power loss, and improves network communication quality.

Q: How to apply for samples? What is the lead time?

A: You can submit a sample application through our website or email. Please provide your company information and target model (including package type requirements). Samples are free of charge and will be shipped within 3-5 working days. Mass order lead time is generally 2-8 weeks.
