High Voltage Ignition Transformer with 8kV Output Voltage and Durable Metal Housing for 33% Duty Cycle Applications

1000
MOQ
High Voltage Ignition Transformer with 8kV Output Voltage and Durable Metal Housing for 33% Duty Cycle Applications
Features Gallery Product Description Chat Now
Features
Specifications
Input Voltage: 220V / 50Hz
Input Current: ≤1.1A
Output Voltage: ≥1×8kV (Single-Pole) Or ≥2×5kV (Dual-Pole)
Output Current: ≥20mA
Ignition Distance: 3-5mm
Highlight:

8kV Output Voltage Ignition Transformer

,

Durable Metal Housing High Voltage Transformer

,

33% Duty Cycle Burner Ignition Transformer
Basic Infomation
Place of Origin: China
Brand Name: SHINHOM
Certification: RoHS/ISO/UL/CE/IATF16949/CNAS
Model Number: HT0207-22-2000
Document: HT0207-22-2000_.pdf
Payment & Shipping Terms
Delivery Time: 2~8weeks
Payment Terms: L/C,T/T
Product Description
High Voltage Ignition Transformer HT0207-22-2000 - Durable Metal Housing for Gas/Oil Burners
This high voltage ignition transformer converts standard low-voltage input into high-voltage output capable of generating a reliable spark across the ignition gap. The HT0207-22-2000 ignition transformer supports both single-pole and dual-pole output configurations, providing flexibility for various burner types and fuel applications. Whether used in natural gas boilers, industrial furnaces, or commercial kitchen equipment, this SHINHOM ignition transformer ensures consistent and dependable ignition performance.
Key Features
  • Rugged Metal Housing - Built with a durable metal enclosure that provides high mechanical strength and excellent thermal management, suitable for harsh industrial conditions.
  • High Output Voltage - Delivers output voltage up to 8kV (single-pole) or 2×5kV (dual-pole), with output current ≥20mA, ensuring reliable spark generation for consistent burner ignition.
  • Flexible Input Options - Supports standard 220V/50Hz AC input with primary current ≤1.1A, compatible with most industrial and commercial power systems.
  • Wide Ignition Gap - With an ignition distance of 3-5mm, provides reliable spark breakdown across the electrode gap for efficient fuel ignition.
  • Intermittent Duty Operation - Designed with a 33% duty cycle (3-minute ignition efficiency), optimized for intermittent ignition applications.
  • Lead Wire Output - Equipped with lead wire terminals for easy integration into existing burner control systems.
  • RoHS Compliant - Manufactured with environmentally friendly materials, meeting RoHS compliance standards.
Technical Specifications
Parameter Specification
Model HT0207-22-2000
Input Voltage 220V / 50Hz
Input Current ≤1.1A
Output Voltage (Single-Pole) ≥1×8kV
Output Voltage (Dual-Pole) ≥2×5kV
Output Current ≥20mA
Ignition Distance 3-5mm
Duty Cycle 33% (3-minute intermittent)
Output Type Single-Pole or Dual-Pole (selectable)
Output Form Lead Wire
Housing Material Metal
RoHS Compliance Yes
Note: Physical dimensions are as per SHINHOM drawing HT0207-22-2000 Rev A0. Custom configurations available upon request.
Applications
  • Gas and Oil Burners - Provides reliable ignition for natural gas, LPG, and oil-fired burners in residential, commercial, and industrial settings.
  • Industrial Boilers - Ensures consistent start-up and safe operation in high-temperature boiler environments.
  • Industrial Furnaces and Kilns - The rugged metal housing withstands high vibration and dusty conditions common in furnace applications.
  • Commercial Kitchen Equipment - Gas stoves, fryers, and ovens benefit from the compact and reliable ignition provided by this transformer.
  • Integrated Burner Systems - Integrates seamlessly into factory-assembled burner units for automated ignition control.
Why Choose the SHINHOM HT0207-22-2000 Ignition Transformer?
As a leading manufacturer in the high voltage ignition transformer market, SHINHOM combines decades of engineering expertise with rigorous quality control. The HT0207-22-2000 burner ignition transformer is designed to deliver reliable performance in the most demanding combustion applications. Its metal housing provides superior protection against mechanical stress and thermal challenges, ensuring long service life and reduced maintenance costs. Additionally, SHINHOM offers customized solutions for output voltage, input voltage, housing materials, and mounting methods to meet specific application requirements.
Frequently Asked Questions
What is the difference between single-pole and dual-pole output for this ignition transformer?
Single-pole output discharges from one high-voltage electrode to ground (the burner metal wall), which is typically used for gas applications. Dual-pole output uses two high-voltage electrodes that discharge across the gap to each other, commonly used for oil and mixed-fuel burners.
Can the HT0207-22-2000 ignition transformer be used for continuous operation?
The standard HT0207-22-2000 is designed for intermittent duty with a 33% duty cycle (3-minute ignition). For continuous-duty requirements, SHINHOM offers customized configurations. Please contact our sales team for specific application needs.
What is the recommended ignition gap for this high voltage ignition transformer?
The recommended ignition distance is 3-5mm for optimal spark performance. Proper gap setting ensures reliable ignition and prevents misfire or excessive electrode wear.
Is the HT0207-22-2000 burner ignition transformer RoHS compliant?
Yes, this SHINHOM ignition transformer is manufactured with RoHS-compliant materials, ensuring environmental safety and regulatory compliance.
Can SHINHOM customize this ignition transformer for my specific application?
Absolutely. SHINHOM supports custom solutions for output voltage, input voltage, housing material, and mounting method based on specific application requirements. Please provide your specifications for a tailored quotation.
