High-Precision Voice Coil Motor for Fast Response Time and Low Power Loss in Linear Motion Applications

MOQ
MOQ
High-Precision Voice Coil Motor for Fast Response Time and Low Power Loss in Linear Motion Applications
Features Gallery Product Description Chat Now
Features
Specifications
Motor Type:: Voice Coil Motor – Designed For Precise Linear Motion And High-response Applications.
Response Time:: Fast Response Time – Ensures Quick And Accurate Movement In Precision Control Systems.
Operating Voltage:: Model-dependent – Compatible With Various Voltage Levels, Optimized For Specific Applications.
Stroke Length:: Adjustable – Customizable Stroke Lengths For Different Application Needs.
DC Resistance:: Low Resistance – Minimizes Power Loss And Enhances System Efficiency.
Core Material:: Ferrite Core – Provides High Magnetic Permeability And Low Core Loss For Efficient Operation.
Operating Temperature:: 0°C To +70°C – Suitable For A Wide Range Of Operating Conditions.
Mechanical Durability:: High Mechanical Stress Resistance – Designed To Withstand Continuous Operation In Demanding Environments.
Customization:: Customizable Design – Can Be Tailored To Meet Specific Application Requirements, Including Stroke Length And Voltage.
Highlight:: Precision Linear Motion, High Response Time, Low Power Loss, Compact Design – Ideal For Automation, Medical, And Optical Systems.
Highlight:

High-Precision Voice Coil Motor

,

Low Power Loss Voice Coil Motor

,

Fast Response Voice Coil Motor
Basic Infomation
Place of Origin: China
Brand Name: SHINHOM
Certification: RoHS/ISO/UL/CE/IATF16949/CNAS
Model Number: Voice Coil Motor
Payment & Shipping Terms
Delivery Time: 2~8weeks
Payment Terms: L/C,T/T
Product Description
High-Precision Voice Coil Motor for Linear Motion and High Response Applications

The Voice Coil Motor is engineered for precision linear motion and high-response applications across various industries including automation, sensors, and medical equipment. Designed to provide accurate and fast movement, this motor delivers exceptional performance with minimal noise and vibration, ensuring smooth operation in critical systems.

Key Features
  • As a Linear Motion Motor, it is optimized for applications requiring precise control and reliable movement, including positioning systems, optics, and high-end robotics. The Precision Voice Coil Motor ensures consistent feedback and smooth motion with high accuracy, making it ideal for sensitive equipment demanding fast response and high precision.
  • This High Response Motor excels in applications where quick adjustments and real-time feedback are crucial. Its compact design and high-performance characteristics make it a reliable choice for demanding, space-constrained environments.
Technical Data
Model Peak Thrust (N) Continuous Thrust (N) Stroke (mm) Current (A) Voltage (V) Mover Mass (g) Stator Mass (g)
Y35-A 1 0.3 4.0 1.0 8 18 30
Y40-A 1.2 0.4 4.0 1.5 12 22 34
Y45-A 1.5 0.7 4.0 1.5 24 28 39
Y63-A 3 1.8 5.0 2.0 12 40 42
Y71-A 5 2.4 8.0 2.8 24 50 70
Y95-A 10 5.5 7.0 3.0 28 125 150
Y110-A 14 7 12.0 3.0 27 180 180
Y112-A 20 8 20.0 3.5 28 200 290
Y130-A 30 12 20.0 4.5 28 360 480
Y180-A 60 30 20.0 8.0 60 610 880
Applications
Automation Systems
Used for precise positioning and motion control in automated machinery and robotics
Medical Devices
Ideal for applications requiring high-precision movement, such as in surgical robots and diagnostic equipment
Sensor Technology
Provides precise motion control for sensors in complex systems, ensuring accurate readings and feedback
Optical Equipment
Used in optical systems for fine adjustments and accurate positioning of lenses and mirrors
Consumer Electronics
Ideal for applications such as camera lenses, speaker drivers, and other devices requiring high-precision motion control
