ETH2321 Series High Current Common Mode Choke 70uH to 480uH for Switching Power Supply Noise Filtering

The ETH2321 series high-current common-mode choke is manufactured using high-quality core materials and advanced winding processes, specifically designed for switching power supplies and DC-DC converters, ensuring high current capacity, high-temperature operation, and excellent common-mode noise filtering. The product features a robust and reliable structure and supports both SMT and THT terminal options. It meets 1500VDC coil-to-coil withstand voltage and wide operating temperature requirements. It is suitable for switching power supplies, industrial power supplies, and communication equipment. It is an ideal choice for high-current applications in common-mode noise filtering and high-current power supplies.

Features

• Current up to 20A
• Inductance – 70µH to 480µH
• SMT and THT terminal options
• High-temperature operation up to 150°C
• Common-mode noise filtering – 500KHz to 10MHz
• Impedance up to 5kΩ
• Coil-to-coil withstand voltage – 1500VDC
• Customisable inductance, impedance, DCR

Product Specification Selection Table

Applications

• Switching power supply noise filtering
• DC-DC converters
• Industrial power modules
• Communication equipment power supplies
• Server power supplies
• Automotive electronics
• Battery management systems
• High-power-density power supplies

FAQ

Q: How to apply for samples? What is the lead time?

A: You can submit a sample application through our website or email. Samples are free of charge and will be shipped within 3-5 working days. Mass order lead time is generally 2-8 weeks; custom products will be confirmed separately.

Q: Do you support small trial orders?

A: Yes. Small trial orders (below the standard MOQ) can be negotiated and receive the same quality standards and delivery commitments as mass orders. Please contact our sales team for details.

Q: Do you provide technical support and selection recommendations?

A: Yes. We have a professional technical team that can provide selection recommendations and customisation solutions based on customer application scenarios and circuit requirements.

Q: Does this product support customisation?

A: Yes. Inductance, impedance, DCR, and current rating can be customised based on customer circuit diagrams or application requirements. Please contact our sales team to confirm the customisation plan.
