Multilayer Ceramic Chip Inductor AIML0805 Series for High Density Installation and Reflow Soldering

The AIML0805 series multi-layer chip inductor features a closed magnetic circuit design that effectively prevents crosstalk. It offers high reliability and excellent solderability, ensuring signal transmission integrity in high-frequency circuits.The product is suitable for high-density mounting and reflow soldering processes, and complies with international standards including FCC, VDE, CSA, VCCI, and CE.Multiple standard sizes from 0402 to 1210 are available to meet different PCB layout requirements.It is widely used in CD-ROMs, hard disk drives, modems, printers, portable devices, medical equipment, test and measurement instruments, converters, automation controllers, and communication equipment.

Features:

1. Avoids crosstalk
2. High reliability
3. Excellent solderability
4. Closed magnetic circuit
5. Closed magnetic circuit avoids crosstalk
6. Sizes 0402 / 0603 / 0805 / 1206 / 1210
7. Suitable for high density installation and re-flow soldering
8. Counter measures for complying with FCC,VDE,CSA,VCCI and CE

Applcations:

1. CD-ROM, Hard Disk, Modem, Printers
2. Printer Equipment
3. Portable Equipment
4. DSC, DVC, PDA, DVD and HDD
5. Medical Equipment
6. Testing/Measurement Equipment
7. Converters
8. Automatic Equipment Controller
9. Communication Device, Cell phone ,GPS ,PDA
10. Personal Computers

Technical information:

1. Testing:(Equivalents acceptable) lnductance & Q-HP4195A+HP41951
2. electrode shall be covered Preheat:@ 180℃±5℃ for 2-3 minutes Solder temperature:230℃for 4 seconds ±1 second Flux:Emersion into methanol solution with Colophony for 3 to 5 seconds.
3. IDC:The DC current at which tither the initial L value is decreased by 5% with the application of DC bias or the value of current at which the temperature of the element is increased by 20℃
4. Operating Temperature:-40℃ to +100℃

Notes: Product size and inductance can be customized

FAQ

Q: What package sizes are available for this series?

A: Five standard sizes are available: 0402, 0603, 0805, 1206, and 1210. They can be flexibly selected based on PCB space and inductance requirements.

Q: Is this product suitable for reflow soldering?

A: Yes. This product is suitable for reflow soldering with excellent solderability, making it suitable for automated SMT production lines and high-density mounting.

Q: How to apply for samples? What is the lead time?

A: You can submit a sample application through our website or email. Please provide your company information and target model (including size and inductance value). Samples are free of charge and will be shipped within 3-5 working days. Mass order lead time is generally 2-8 weeks.
